Electrical Control Panel Design & Fabrication is a critical discipline in industrial automation and electrical engineering. It involves designing and building custom enclosures that house electrical components used to control equipment and processes safely and efficiently.
An electrical control panel is a centralized enclosure that contains electrical devices such as:
Circuit breakers & fuses
Relays & contactors
PLCs and I/O modules
Motor starters and drives (VFDs)
Power supplies
Terminal blocks
Wiring and labeling
Panels can be custom-designed for various applications, from simple motor starters to complex multi-panel automation systems.
1. Requirements Definition
Load list: What will the panel control?
Input/output specifications
Voltage and current requirements
Safety and compliance standards (e.g., UL 508A, IEC, NEC)
2. Electrical Schematics
Developed using CAD tools (e.g., AutoCAD Electrical, EPLAN).
Includes:
Power circuits
Control circuits
I/O wiring diagrams
Interconnection and terminal layouts
3. Component Selection
Based on function, voltage, current, space, and budget.
Common components include:
PLCs (Siemens, Allen-Bradley, Schneider)
Relays, contactors, timers
VFDs or soft starters
Indicators, switches, HMI
4. Panel Layout Design
DIN rail placement
Cable duct routing
Heat management (fans, vents, cooling units)
Accessibility for wiring and maintenance
5. Compliance & Standards
Design for compliance with:
UL 508A (US)
IEC 61439 (Europe)
NEC / NFPA 70 (US electrical code)
CE Marking (EU)
Labeling and color coding standards
1. Material Procurement
Panel enclosures (sheet metal, stainless steel, polycarbonate)
Electrical components
Labeling materials
2. Enclosure Preparation
Cutting holes for push buttons, HMIs, cable entries
Mounting DIN rails and backplates
3. Component Installation
Mounting breakers, PLCs, relays, etc.
Internal wiring with proper gauge and color-coded wires
Labeling of terminals and wires
4. Wiring & Testing
Continuity and insulation testing
Load and short-circuit protection verification
Power-up testing and simulation (dry run)
5. Documentation
Complete set of schematics
Panel layout drawings
Bill of materials (BOM)
Test reports and certification documentation
| Panel Type | Description |
|---|---|
| MCC (Motor Control Center) | Centralized panel for multiple motors with starters, overloads. |
| PLC Panel | Houses PLCs, I/O modules, relays, and communication devices. |
| VFD Panel | Includes variable frequency drives for motor speed control. |
| Remote I/O Panel | Extends control to distributed locations. |
| Operator Consoles | Integrated with HMI for manual operation. |
